DC Voltage 400mV/4V/40V/400V/1000V (0.8%+8)
AC Voltage 4V/40V/400V/750V (1%+15)
DC Current 400mA /4000mA/40mA/400mA/4A/10A (1%+8)
AC Current 400mA/4000mA/40mA/400mA/4A/10A (1.5%+8)
Resistance 400W/ 4kW/40kW/400kW/4MW/ 40MW (1%+5)
Capacitance 40nF /400nF/4mF/40mF/100mF (3%+8)
Frequency 10Hz~10MHz (0.1%+3)
Vertical Accuracy (5%+1)
Input Sensitivity 20mV/div-500V/div (1-2-5) Horizontal Accuracy (0.01%+1)
Timebase Range 100ns/div-5s/div (1-2-5) Bandwidth 8MHz
Display Resolution 160X160
Real-Time Sample Rate 40MSa/s
Duty Cycle 0.1%~99.9%
Display 160x160 Monochrome
Trigger Types Free Run / Normal / Single Shot
Memory 10 screens and setups
